PLASMA 75 Wood
Front wood-burning fireplace
Front wood-burning fireplace with innovative features. It offers high-performance and ease to use.
The combustion air and glass cleaning inlets can be fully ducted to the outside (BE type appliance – Combustion air completely ductable, not hermetict).
Ask for a quote
New intuitive and simplified adjustment system
“Easy Going”, the new intuitive and simplified adjustment system, was designed with the user in mind: instead of technical concepts relating to the stages of combustion, there is a simple choice of 5 options corresponding to the actual situations of use of the fireplace:
- “start” for a quick ignition of the flame
- “clean”, the air option for the glass cleaning
- “comfort” for a lively flame with the right balance of primary and secondary air
- “performance” for a better heat exchange of the fireplace
- “sleep” for a combustion with very little oxygen to increase the fuel duration
Self-cleaning heart in Alutec®
Alutec® is the exclusive material developed and patented by MCZ for all its fireplaces. A patented formula of high alumina content achieved by processing at temperatures of up to 300 °C allows guaranteed self-cleaning of the combustion chamber through a chemical reaction. With its light colour, it makes the flame uniquely bright and even more beautiful.
Read MoreOpening with handle or cool handle at 90 or 45°
The look of the fireplace can be customized by choosing the handle that blends in best with the room. The “Easy Switch” system offers in fact the option of using either the handle or the cool handle, prioritising ergonomics or very clean aesthetics, respectively. Without handle (cool handle) the doors opens at 90° for cleaning. With handle the door opening is at 45°.
Read More“Environmentally friendly” design
The new combustion is high-performing and efficient in accordance with the strictest regulations in terms of emissions (Ecodesign 2022).
Read MoreVaste range of solutions
Plasma collection includes:
- four front models, 75, 85, 95 and 115 centimeters in width
- two dual-faced models, 95 and 115 centimeters in width
- two corner models, 75 and 95 centimeters in width
- two three sided models, 50 and 95 centimeters in width
Making the most of heat
Plasma fireplaces are designed to guarantee maximum exploitation of the heat, whether natural convection is used, or forced ventilation is the preferred choice.
All Plasma fireplaces can be teamed with the patented COMFORT AIR® system, that makes it possible to convey the hot air to several rooms – even unconnected – at a distance of up to 8 metres.
Read MoreFind the distributor closest to you
Click below to find your nearest stockist or enquire with a dealer to find out more or arrange an in-store demo
Find a distributorTECHNICAL DATA & DOCUMENTATION DOWNLOADS Plasma 75 Wood
| PLASMA 75 WOOD Model: PLASMA 75 WOOD (5017012) | ||||
|---|---|---|---|---|
| Energy efficiency class | A | Hourly consumption at Max | 3.90 kg/h (**) | |
| Seasonal space heating energy efficiency (ηs) | 70.00 % | Heatable volume 20W/m³ | 665.00 m3 (*) | |
| Dimensions (LxHxP) | 84.6 x 156.2 x 53.8 cm | Heatable volume 35W/m³ | 380.00 m3 (*) | |
| Nominal heat output | 12.50 kW | Heatable volume 55W/m³ | 242.00 m3 (*) | |
| Minimum heat output | 6.00 kW | Smoke outlet | 200 mm | |
| Efficiency at Max | 80.30 % | Net weight | 328.00 kg | |
| Efficiency at Min | 81.30 % | Temperature of exhaust smoke | 271.00 °C | |
| Hourly consumption at Min | 1.90 kg/h (**) | Mass of smoke | 11.90 g/s | |
(*) The declared volume represents the number of cubic metres that can be heated by the product based on the average demand of the house (expressed in W/m3). The values given are purely indicative, a professional assessment is required for mandatory energy calculations.
(**) Data that may differ depending on the fuel used.
